RECYFIX STANDARD

Suitable for pedestrian zones & light commercial traffic.

Your benefits with RECYFIX STANDARD

The durable and corrosion resistant RECYFIX STANDARD channels are easy to transport and simple to install. With a load capacity of up to C 250, the channels are particularly suitable for public squares, gardens and parks. The systems are available in nominal sizes from 100 mm to 300 mm with different constructed heights as well as preformed vertical and horizontal outlets.

  • Channel body made of highly stable and approx. 93% RECYFIX material (certified by the ‘Blue Angel’ eco-label)
  • Smooth internal surfaces achieve superior hydraulic flow characteristics
  • Composite frame stops any lateral movement and enables flush connection with gratings rn
  • Stable gratings in load classes A 15 to C 250 according to EN 1433 in ductile iron, galvanised or stainless steel
  • Lightweight and pre-assembled units with simple joint design for easy installation
  • Composite channel bodies can be cut, drilled and easily worked on on-site
  • Resistance to weather influences such as frost, heat and humidity
  • Permanently withstand the daily stress of cars and pedestrians

The HAURATON Product Finder

Find the right product for your project, information for your planning, tender texts, product illustrations, technical drawings and CAD data etc.
Unfold all groups
  • RECYFIX STANDARD 100, class A 15

    • RECYFIX STANDARD 100, trafficable

      • RECYFIX STANDARD 100, class B 125

        • RECYFIX STANDARD 100, class C 250

          • RECYFIX STANDARD 150, class B 125

            • RECYFIX STANDARD 150, class C 250

              • RECYFIX STANDARD 200, class B 125

                • RECYFIX STANDARD 200, class C 250

                  • RECYFIX STANDARD 300, class B 125

                    • RECYFIX STANDARD 300, class C 250

                      Unfold all groups

                      Material made from recycled composite


                      The RECYFIX material used to manufacture the channel bodies is made from approximately 93% recycled composite and, for this reason, bears the well-known German ‘Blue Angel’ eco-label. This helps to preserve fossil fuel resources, reduce waste and minimise the environmental impact of production. RECYFIX channels are PVC-free and suitable for material or thermal recovery  at the end of their life.
